CHASSIS:
- Ford F550 4X4
- 6.7L V8 Diesel Engine with 10-speed transmission
- 19,500 GVWR
- Engine block heater, dual fuel tanks, and 350-amp alternator
- FOX Racing shocks and springs with 3-inch lift
- 35-inch tires on 20-inch black-out rims
- 7-inch viewing screen with backup, left, and right turn cameras
- Factory in-dash stereo system
- Heavy-duty front and rear bumpers
- Front 15,000-watt winch with controller
- Nerf bars
- Pass-through between cab and habitat
- 7-pin trailer connection
- 2-inch receiver at rear bumper
- Remote start
EXTERIOR:
- RS-designed self-supporting body and frame
- Articulating step for easy entry and exit
- Grab handle and railing at entry door
- Full basement with compartment doors
- Fully painted body to match truck
- Accessible exterior storage doors for tanks
- Self-contained components within the shell, allowing habitat unbolting from chassis
INTERIOR:
- Large dining table for 6, converts to King Bed
- High ceilings with premium soft touch headliner
- Closet with shelves and hanging rod
- Under-dinette storage
- Cab over storage
- Commercial-grade flooring for easy cleaning
- Premium seating material
- Commercial-grade laminate cabinets with soft close mechanism
- Push button latches
- Solid surface countertops throughout
- Cabover bunk with escape hatch
EXTERIOR LIGHTING:
- 52-inch LED light bar on front of cab
LED tail and brake lights, upper and lower, & marker lights; LED reverse lights; LED rear license plate light; fog lights; OEM driving lights; 3-LED 12” security lights; zoned interior lighting; independent on/off switches for overheads, bathroom, dinette, kitchen, and outside security lights; residential-style stainless-steel sink with large faucet; under-cabinet storage for trash can; solid surface countertops; removable-double burner induction cooktop; convection microwave/oven; refrigerator/freezer; exhaust hood; overhead and base cabinets; washer/dryer cabinet with pull-out storage drawer; countertop space with outlets for charging; wall-mounted Smart TV; ceiling skylight; residential-style, fully dry, enclosed bathroom with toilet; walk-in shower; vanity mirror; floor-to-ceiling storage cabinet beside toilet; lower cabinet storage with pass-through to rear exterior storage; removable shower wand on height-adjustable slide bar; sink with premium fixtures; premium toilet paper holder; shower with skylight for extra lighting and headroom; variable speed exhaust fan with rain cover; industry-leading off-grid electrical system: 48 Volt Energy System (2 times more efficient than leading competitors’ 24 Volt systems and 4 times more efficient than a 12 Volt system); 50 Amp Service; 6000 Watts of inverter power; available run time
Max A/C, leading the industry at 21 Hours, offers a fully functional system running for 10 hours (solar/alternator/shore power adds time). Recharge time at full capacity is less than 5 hours, while with sunlight, it’s just over 3 hours. A 17 Kilowatts energy storage system with two 8440 Watt Hour Module Lithionics UL listed lithium-ion batteries provides supplemental charging. A market-leading remote interface with Bluetooth and Wi-Fi-based app offers state-of-the-art system control and monitoring. 120V AC outlets are located in various areas, including overhead, dinette, kitchen, washer/dryer cabinet, bathroom, and storage. A 20 Amp AC outlet is in a compartment.
Plumbing includes a self-contained and heated 75 Gallon fresh water holding tank, a 40 Gallon self-contained and heated waste black tank, and a 30 Gallon self-contained and heated waste grey tank. Tank monitoring and a high-capacity water pump are also included. An exterior shower with hot and cold water is available.
For cooling, heating, and ventilation, a nomadic cooling system with a 3000 48 Volt A/C, 12,480 BTU, comes standard with a 48 Volt brushless motor. Two thermostat-controlled toe kick heaters are also available. Dual pane windows allow for natural light. A roof hatch with a vent fan, screen, and escape hatch is included.
Safety features include carbon monoxide/smoke detectors, a fire extinguisher, and a roadside safety kit. Accessories include a fresh water hose, a waste tank hose, and a 50 Amp shore cord.
